Карбюратор TOYOTA TOYOACE

21112

HORN, AIR

21129

COVER(FOR THERMOSTATIC VALVE)

21205

JET SUB-ASSY, SLOW

21206

STRAINER SUB-ASSY

21209

FLOAT SUB-ASSY

21211

VENTURI, 1ST SMALL

21212

VENTURI, 2ND SMALL

21251

JET, 1ST MAIN

21253

JET, 2ND MAIN

21255

JET, POWER

21291

GLASS, LEVEL GAGE

21301

VALVE SUB-ASSY, NEEDLE

21313

BALL, STEEL, NO.1(FOR DISCHARGE WEIGHT)

21314

BALL, STEEL, NO.2(FOR PUMP PLUNGER)

21334

VALVE, CHOKE

21335

VALVE, THERMOSTATIC

21341

VALVE, POWER

21351

PISTON, POWER

21353

PLUNGER, PUMP

2139931240

Крепеж

21414

SHAFT, CHOKE

21454

LEVER, CHOKE

21481

CONNECTOR, 1ST IDLE

21511

CLAMP, LEVEL GAGE

21538

RETAINER, BALL CHECK

21561

WEIGHT, PUMP DISCHARGE

21572

STOP, POWER PISTON

21575

STOPPER, B(FOR DISCHARGE WEIGHT)

21611

GASKET, MAIN JET

21611

GASKET, MAIN JET

21614

GASKET, VENTURI

21614

GASKET, VENTURI

21617

GASKET, MAIN PASSAGE PLUG

21617

GASKET, MAIN PASSAGE PLUG

21618

GASKET, NEEDLE VALVE SEAT

21621

GASKET, UNION NIPPLE

21621

GASKET, UNION NIPPLE

21622

GASKET, AIR HORN

21625

GASKET, LEVEL GAGE

21641

GASKET(FOR THERMOSTATIC VALVE COVER)

21649

GASKET(FOR PUMP DISCHARGE WEIGHT STOPPER)

21659

RING, O(FOR THERMOSTATIC VALVE)

21699

BOOT(FOR PUMP PLUNGER)

21722

SPRING, PUMP DAMPING

21734

SPRING, POWER PISTON

21738

SPRING, CHOKE VALVE RELIEF

21751

UNION, NIPPLE

21763

PIN, FLOAT LEVER

21781

PLUG, MAIN PASSAGE(FOR CARBURETOR JET)

21781

PLUG, MAIN PASSAGE(FOR CARBURETOR JET)

21785

PLUG, CARBURETOR FUEL INLET STRAINER

21791

RING, SNAP, NO.1(FOR CARBURETOR LINK)

21823

SCREW, CHOKE, VALVE SET

21831

SCREW, POWER PISTON STOP

21832

SCREW(FOR CHOKE LEVER ADAPTER SET)

21842

SCREW, SET(FOR CARBURETOR LEVEL GAGE CLAMP SET)

2184333080

Крепеж

9321914008

Крепеж

9321914010

Крепеж

9321914018

Крепеж

9321915010

Крепеж

9331915020

Крепеж

9451100400

Крепеж

9451100400

Крепеж

9451100400

Крепеж

9451100400

Крепеж

9451100500

Крепеж

21113

FLANGE, CARBURETOR

21271

SCREW, IDLE ADJUSTING

21272

SCREW, 1ST IDLE ADJUSTING

21273

SCREW, THROTTLE ADJUSTING

21277

SCREW, LOW IDLE ADJUSTING

21331

VALVE, 1ST THROTTLE

21332

VALVE, 2ND THROTTLE

21333

VALVE, HIGH SPEED

21411

SHAFT, HIGH SPEED

21412

SHAFT, 1ST THROTTLE

21413

SHAFT, 2ND THROTTLE

21431

ARM, 1ST THROTTLE SHAFT

21432

ARM, THROTTLE

21452

LEVER, PUMP

21453

LEVER, 1ST THROTTLE

21456

LEVER, 1ST THROTTLE IDLE ADJUSTING, NO.1

21471

LINK, PUMP CONNECTING

21472

LINK, PUMP CONNECTING, NO.2

21473

LINK, THROTTLE SHAFT

21525

SUPPORT, ACCELERATOR LINK

21526

SUPPORT, BACK SPRING

21557

SPACER(FOR 1ST IDLE CAM)

21581

SHIM, 1ST THROTTLE SHAFT

21581

SHIM, 1ST THROTTLE SHAFT

21623

GASKET, BODY FLANGE

21672

CAP

21681

SHIM(FOR HIGH SPEED SHAFT)

21723

SPRING, IDLE ADJUSTING

21724

SPRING, THROTTLE ADJUSTING

21725

SPRING, 2ND THROTTLE BACK

21726

SPRING, 1ST IDLE ADJUSTING

21729

SPRING, 1ST THROTTLE BACK

21733

SPRING, LOW IDLE ADJUSTING

21735

SPRING, PUMP ARM

21791

RING, SNAP, NO.1(FOR CARBURETOR LINK)

21791

RING, SNAP, NO.1(FOR CARBURETOR LINK)

21794

RING, RETAINER, NO.1(FOR THROTTLE SHAFT)

21794

RING, RETAINER, NO.1(FOR THROTTLE SHAFT)

21795

RING, RETAINER, NO.2(FOR HIGH SPEED SHAFT)

21821

SCREW, 2ND THROTTLE VALVE SET

21822

SCREW, 1ST THROTTLE VALVE SET

21826

SCREW, PUMP ARM SET

21829

SCREW, HIGH SPEED VALVE SET

21833

SCREW, SET, NO.1(FOR CARBURETOR BODY SET)

21834

SCREW, SET, NO.2(FOR CARBURETOR BODY SET)

21834

SCREW, SET, NO.2(FOR CARBURETOR BODY SET)

21852

NUT, THROTTLE LEVER SET

21881

WASHER, LOCK(FOR THROTTLE SHAFT)

9315016014

Крепеж

9451100500

Крепеж

9451200600

Крепеж

9451200600

Крепеж

9451200600

Крепеж

9461110300

Крепеж

9461110300

Крепеж

9461110400

Крепеж

9461110400

Крепеж

9461110400

Крепеж

9538101610

Крепеж

9538101610

Крепеж

9538101610

Крепеж

21112

HORN, AIR

21123

HOUSING, DIAPHRAGM

21129

COVER(FOR THERMOSTATIC VALVE)

21138

CAP, DIAPHRAGM

21205

JET SUB-ASSY, SLOW

21209

FLOAT SUB-ASSY

21211

VENTURI, 1ST SMALL

21212

VENTURI, 2ND SMALL

21251

JET, 1ST MAIN

21253

JET, 2ND MAIN

21255

JET, POWER

21291

GLASS, LEVEL GAGE

21301

VALVE SUB-ASSY, NEEDLE

21313

BALL, STEEL, NO.1(FOR DISCHARGE WEIGHT)

21314

BALL, STEEL, NO.2(FOR PUMP PLUNGER)

21335

VALVE, THERMOSTATIC

21341

VALVE, POWER

21351

PISTON, POWER

21353

PLUNGER, PUMP

2139931240

Крепеж

21454

LEVER, CHOKE

21511

CLAMP, LEVEL GAGE

2152424230

Крепеж

21526

SUPPORT, BACK SPRING

21538

RETAINER, BALL CHECK

21572

STOP, POWER PISTON

21575

STOPPER, B(FOR DISCHARGE WEIGHT)

21611

GASKET, MAIN JET

21611

GASKET, MAIN JET

21614

GASKET, VENTURI

21614

GASKET, VENTURI

21617

GASKET, MAIN PASSAGE PLUG

21617

GASKET, MAIN PASSAGE PLUG

21618

GASKET, NEEDLE VALVE SEAT

21621

GASKET, UNION NIPPLE

21622

GASKET, AIR HORN

21625

GASKET, LEVEL GAGE

21641

GASKET(FOR THERMOSTATIC VALVE COVER)

21645

GASKET, DIAPHRAGM, CAP

21647

GASKET, DIAPHRAGM HOUSING CAP

21649

GASKET(FOR PUMP DISCHARGE WEIGHT STOPPER)

21659

RING, O(FOR THERMOSTATIC VALVE)

21698

DIAPHRAGM

21699

BOOT(FOR PUMP PLUNGER)

21722

SPRING, PUMP DAMPING

21734

SPRING, POWER PISTON

21751

UNION, NIPPLE

21763

PIN, FLOAT LEVER

21781

PLUG, MAIN PASSAGE(FOR CARBURETOR JET)

21781

PLUG, MAIN PASSAGE(FOR CARBURETOR JET)

2179440070

Крепеж

2182124030

Крепеж

2182125010

Крепеж

2182131140

Крепеж

21831

SCREW, POWER PISTON STOP

21832

SCREW(FOR CHOKE LEVER ADAPTER SET)

2183433080

Крепеж

21842

SCREW, SET(FOR CARBURETOR LEVEL GAGE CLAMP SET)

21867

SPRING, DIAPHRAGM

2188544010

Крепеж

2189731270

Крепеж

2189831270

Крепеж

21934

SOLENOID, THROTTLE VALVE

9321914008

Крепеж

9321914018

Крепеж

9321914018

Крепеж

9321915010

Крепеж

9321915018

Крепеж

9321915025

Крепеж

9451100400

Крепеж

9451100400

Крепеж

9451100400

Крепеж

9451100400

Крепеж

9451100500

Крепеж

9451100500

Крепеж

9451100500

Крепеж

9461110300

Крепеж

21113

FLANGE, CARBURETOR

21271

SCREW, IDLE ADJUSTING

21272

SCREW, 1ST IDLE ADJUSTING

21273

SCREW, THROTTLE ADJUSTING

21331

VALVE, 1ST THROTTLE

21332

VALVE, 2ND THROTTLE

21334

VALVE, CHOKE

21377

COLLAR(FOR 2ND THROTTLE SHAFT)

21412

SHAFT, 1ST THROTTLE

21413

SHAFT, 2ND THROTTLE

21414

SHAFT, CHOKE

21431

ARM, 1ST THROTTLE SHAFT

21447

LEVER, DIAPHRAGM

21449

LEVER, 2ND KICK

21452

LEVER, PUMP

21453

LEVER, 1ST THROTTLE

21456

LEVER, 1ST THROTTLE IDLE ADJUSTING, NO.1

21471

LINK, PUMP CONNECTING

21481

CONNECTOR, 1ST IDLE

21502

CLAMP SUB-ASSY, CHOKE WIRE

21557

SPACER(FOR 1ST IDLE CAM)

21581

SHIM, 1ST THROTTLE SHAFT

21581

SHIM, 1ST THROTTLE SHAFT

2158321010

Крепеж

21623

GASKET, BODY FLANGE

2166831240

Крепеж

21672

CAP

21723

SPRING, IDLE ADJUSTING

21724

SPRING, THROTTLE ADJUSTING

21726

SPRING, 1ST IDLE ADJUSTING

21735

SPRING, PUMP ARM

21738

SPRING, CHOKE VALVE RELIEF

21756

SPRING, BACK(FOR THROTTLE SHAFT)

21756

SPRING, BACK(FOR THROTTLE SHAFT)

21791

RING, SNAP, NO.1(FOR CARBURETOR LINK)

21791

RING, SNAP, NO.1(FOR CARBURETOR LINK)

21794

RING, RETAINER, NO.1(FOR THROTTLE SHAFT)

21821

SCREW, 2ND THROTTLE VALVE SET

21822

SCREW, 1ST THROTTLE VALVE SET

21823

SCREW, CHOKE, VALVE SET

21826

SCREW, PUMP ARM SET

21833

SCREW, SET, NO.1(FOR CARBURETOR BODY SET)

21834

SCREW, SET, NO.2(FOR CARBURETOR BODY SET)

21834

SCREW, SET, NO.2(FOR CARBURETOR BODY SET)

21852

NUT, THROTTLE LEVER SET

21852

NUT, THROTTLE LEVER SET

21868

SPRING, DIAPHRAGM RELIEF

21881

WASHER, LOCK(FOR THROTTLE SHAFT)

21881

WASHER, LOCK(FOR THROTTLE SHAFT)

2189731240

Крепеж

9318016018

Крепеж

9411040800

Крепеж

9451100500

Крепеж

9451200600

Крепеж

9451200600

Крепеж

9451200600

Крепеж

9461110300

Крепеж

9461110400

Крепеж

9538101610

Крепеж

21112

HORN, AIR

21123

HOUSING, DIAPHRAGM

21129

COVER(FOR THERMOSTATIC VALVE)

21138

CAP, DIAPHRAGM

21205

JET SUB-ASSY, SLOW

21209

FLOAT SUB-ASSY

21211

VENTURI, 1ST SMALL

21212

VENTURI, 2ND SMALL

21251

JET, 1ST MAIN

21253

JET, 2ND MAIN

21255

JET, POWER

21291

GLASS, LEVEL GAGE

21301

VALVE SUB-ASSY, NEEDLE

21313

BALL, STEEL, NO.1(FOR DISCHARGE WEIGHT)

21314

BALL, STEEL, NO.2(FOR PUMP PLUNGER)

21335

VALVE, THERMOSTATIC

21341

VALVE, POWER

21351

PISTON, POWER

21353

PLUNGER, PUMP

2139931240

Крепеж

21454

LEVER, CHOKE

21511

CLAMP, LEVEL GAGE

2152424230

Крепеж

21526

SUPPORT, BACK SPRING

21538

RETAINER, BALL CHECK

21572

STOP, POWER PISTON

21575

STOPPER, B(FOR DISCHARGE WEIGHT)

21611

GASKET, MAIN JET

21611

GASKET, MAIN JET

21614

GASKET, VENTURI

21614

GASKET, VENTURI

21617

GASKET, MAIN PASSAGE PLUG

21617

GASKET, MAIN PASSAGE PLUG

21618

GASKET, NEEDLE VALVE SEAT

21621

GASKET, UNION NIPPLE

21622

GASKET, AIR HORN

21625

GASKET, LEVEL GAGE

21641

GASKET(FOR THERMOSTATIC VALVE COVER)

21645

GASKET, DIAPHRAGM, CAP

21647

GASKET, DIAPHRAGM HOUSING CAP

21649

GASKET(FOR PUMP DISCHARGE WEIGHT STOPPER)

21659

RING, O(FOR THERMOSTATIC VALVE)

21698

DIAPHRAGM

21699

BOOT(FOR PUMP PLUNGER)

21722

SPRING, PUMP DAMPING

21734

SPRING, POWER PISTON

21751

UNION, NIPPLE

21763

PIN, FLOAT LEVER

21781

PLUG, MAIN PASSAGE(FOR CARBURETOR JET)

21781

PLUG, MAIN PASSAGE(FOR CARBURETOR JET)

2179440070

Крепеж

2182124030

Крепеж

2182125010

Крепеж

2182131140

Крепеж

21831

SCREW, POWER PISTON STOP

21832

SCREW(FOR CHOKE LEVER ADAPTER SET)

2183433080

Крепеж

21842

SCREW, SET(FOR CARBURETOR LEVEL GAGE CLAMP SET)

21867

SPRING, DIAPHRAGM

2188544010

Крепеж

2189731300

Крепеж

2189831280

Крепеж

21934

SOLENOID, THROTTLE VALVE

9321914008

Крепеж

9321914018

Крепеж

9321914018

Крепеж

9321915010

Крепеж

9321915018

Крепеж

9451100400

Крепеж

9451100400

Крепеж

9451100400

Крепеж

9451100400

Крепеж

9451100500

Крепеж

9451100500

Крепеж

9461110300

Крепеж

21113

FLANGE, CARBURETOR

21271

SCREW, IDLE ADJUSTING

21272

SCREW, 1ST IDLE ADJUSTING

21273

SCREW, THROTTLE ADJUSTING

21331

VALVE, 1ST THROTTLE

21332

VALVE, 2ND THROTTLE

21334

VALVE, CHOKE

21412

SHAFT, 1ST THROTTLE

21413

SHAFT, 2ND THROTTLE

21414

SHAFT, CHOKE

21431

ARM, 1ST THROTTLE SHAFT

21444

LEVER(FOR RELOADER LINK MECHANISM)

21447

LEVER, DIAPHRAGM

21449

LEVER, 2ND KICK

21452

LEVER, PUMP

21453

LEVER, 1ST THROTTLE

21456

LEVER, 1ST THROTTLE IDLE ADJUSTING, NO.1

21471

LINK, PUMP CONNECTING

21481

CONNECTOR, 1ST IDLE

21484

CONNECTOR(FOR OPENER)

21502

CLAMP SUB-ASSY, CHOKE WIRE

21557

SPACER(FOR 1ST IDLE CAM)

21581

SHIM, 1ST THROTTLE SHAFT

21581

SHIM, 1ST THROTTLE SHAFT

21583

SHIM, 2ND THROTTLE SHAFT

21623

GASKET, BODY FLANGE

21668

COLLAR

21668

COLLAR

2166831240

Крепеж

21672

CAP

2171238010

Крепеж

21723

SPRING, IDLE ADJUSTING

21724

SPRING, THROTTLE ADJUSTING

21726

SPRING, 1ST IDLE ADJUSTING

21728

SPRING, THROTTLE VALVE RETURN

21735

SPRING, PUMP ARM

21738

SPRING, CHOKE VALVE RELIEF

21756

SPRING, BACK(FOR THROTTLE SHAFT)

21791

RING, SNAP, NO.1(FOR CARBURETOR LINK)

21791

RING, SNAP, NO.1(FOR CARBURETOR LINK)

21791

RING, SNAP, NO.1(FOR CARBURETOR LINK)

21794

RING, RETAINER, NO.1(FOR THROTTLE SHAFT)

21821

SCREW, 2ND THROTTLE VALVE SET

21822

SCREW, 1ST THROTTLE VALVE SET

21823

SCREW, CHOKE, VALVE SET

21826

SCREW, PUMP ARM SET

21833

SCREW, SET, NO.1(FOR CARBURETOR BODY SET)

21834

SCREW, SET, NO.2(FOR CARBURETOR BODY SET)

21834

SCREW, SET, NO.2(FOR CARBURETOR BODY SET)

21852

NUT, THROTTLE LEVER SET

21852

NUT, THROTTLE LEVER SET

21864

SPRING(FOR 1ST THROTTLE ARM)

21868

SPRING, DIAPHRAGM RELIEF

2187321010

Крепеж

21881

WASHER, LOCK(FOR THROTTLE SHAFT)

21881

WASHER, LOCK(FOR THROTTLE SHAFT)

2189731240

Крепеж

2189731250

Крепеж

9111140616

Крепеж

9451100500

Крепеж

9451200600

Крепеж

9451200600

Крепеж

9451200600

Крепеж

9461110300

Крепеж

9538101610

Крепеж
