Япония

Модель

LAND CRUISER S/T,H/T

VIN

Дата

1992/08

Двигатель

2,4 литра, турбо-дизель

Кузов

фургон

Класс

SX-5 SPECIFICATION

Фрейм

LJ78

КПП

автомат

Опции

Q TYPE обычное пассажирское авто

WINCH TOYOTA LAND CRUISER S/T,H/T







Код

Описание

3603

переход к группе запчастей

38101

CASE SUB-ASSY, WINCH GEAR

38101D

PLUG, BREATHER (FOR WINCH GEAR CASE)

38101E

PLUG (FOR WINCH GEAR CASE)

38101E

PLUG (FOR WINCH GEAR CASE)

38105

COVER SUB-ASSY, WINCH GEAR CASE

38105B

PLUG, TIGHT (FOR WINCH GEAR CASE COVER)

38105C

RING, O (FOR WINCH GEAR CASE COVER)

38110

WINCH ASSY

38113C

RETAINER, WORM BEARING, NO.1

38113E

RING, O (FOR WINCH WORM BEARING RETAINER NO.1)

38114

BOLT, WINCH WORM BEARING RETAINER

38117

SEAL, WINCH GEAR CASE COVER

3811860040

Крепеж

38119

CLIP, WINCH GEAR CASE COVER

38121

GASKET, WINCH GEAR CASE COVER

38123A

SHIM, WINCH WORM ADJUST, NO.1

38123A

SHIM, WINCH WORM ADJUST, NO.1

38131

GEAR, WORM

38135

WORM, WINCH

38135B

BEARING (FOR WINCH WORM)

38135B

BEARING (FOR WINCH WORM)

38141

DRUM, WINCH

3814360010

Крепеж

3815360040

Крепеж

38175

SPRING, WINCH BRAKE, NO.1

38175A

BALL (FOR WINCH BRAKE SPRING NO.1)

38176

SPRING, WINCH BRAKE, NO.1

38181

PIN, WINCH BRAKE

38201

LEVER SUB-ASSY, WINCH CLUTCH

38204

SHAFT ASSY, WINCH CLUTCH HUB

38206

BRAKE ASSY, WINCH

38213A

SPRING, WINCH CLUTCH HUB SHIFT

38221A

BUSH (FOR CLUTCH HUB SHIFT LEVER)

38221A

BUSH (FOR CLUTCH HUB SHIFT LEVER)

38225

KNOB, WINCH CLUTCH LEVER

38227

PLATE, WINCH CLUTCH LEVER SHIFT LOCK

38229A

COVER, WINCH CLUTCH

38235

CHAIN, WINCH CLUTCH LEVER

38286

COVER, WINCH

38301

BRACKET SUB-ASSY, WINCH END

38340

WIRE ASSY, WINCH CHAIN

38344

GUIDE, WINCH WIRE

38351

BASE, WINCH

38360

BRACKET ASSY, WINCH ROLLER

38380

HOLDER ASSY, WINCH HOOK

9011908754

Крепеж

9011910495

Крепеж

9011910495

Крепеж

9011912200

Крепеж

9015940179

Крепеж

9017908028

Крепеж

9024005004

Крепеж

9031128004

Крепеж

9036006004

Крепеж

9046812018

Крепеж

9161160820

Крепеж

9165161020

Крепеж

91651A0816

Крепеж

91651B0818

Крепеж

9338118014

Крепеж

9411040800

Крепеж

9451200800

Крепеж

9461210800

Крепеж

9616000400

Крепеж

9616000600

Крепеж

Код

Описание

38110

WINCH ASSY

38182B

BOLT, WINCH, NO.1

38182B

BOLT, WINCH, NO.1

38183A

BOLT, WINCH, NO.2

38191

PLATE, WINCH CAUTION, NO.1

38192

PLATE, WINCH CAUTION, NO.2

38193

PLATE, WINCH CAUTION, NO.3

38286

COVER, WINCH

38331

BASE, WINCH, NO.1

38332

BASE, WINCH, NO.2

38360

BRACKET ASSY, WINCH ROLLER

38380

HOLDER ASSY, WINCH HOOK

38600A

MOTOR ASSY, W/MAGNET SWITCH, WINCH

38600B

RING, O (FOR WINCH MOTOR)

38630

SWITCH ASSY, MAGNET, NO.1

38640

SWITCH ASSY, WINCH CONTROL

38649

WIRE, WINCH CONTROL

38659

COVER, WINCH CONTROL SWITCH

9017908204

Крепеж

9017908204

Крепеж

91651A0816

Крепеж

9165961225

Крепеж

9411571200

Крепеж

9461110800

Крепеж

9461110800

Крепеж

Код

Описание

28199B

PROTECTOR, DUST WINCH MOTOR

38600A

MOTOR ASSY, W/MAGNET SWITCH, WINCH

38601A

YOKE SUB-ASSY, WINCH MOTOR

38603A

ARMATURE SUB-ASSY, WINCH MOTOR

38603B

BEARING, NO.1 (FOR WINCH MOTOR ARMATURE)

38603C

BEARING, NO.2 (FOR WINCH MOTOR ARMATURE)

38604A

HOLDER ASSY, WINCH MOTOR BRUSH

38610A

MOTOR ASSY, WINCH

38611B

SWITCH, MAGNET, NO.2 (FOR WINCH MOTOR)

38611B

SWITCH, MAGNET, NO.2 (FOR WINCH MOTOR)

38612A

FRAME, WINCH MOTOR END

38613A

BRUSH, WINCH MOTOR

38613B

SPRING, WINCH MOTOR BRUSH

38614A

RING, O(FOR WINCH MOTOR)

38618

FRAME, WINCH MOTOR COMMUTATOR END

38621B

COVER, MAGNET SWITCH WINCH

38623

STOPPER, WINCH MOTOR

38623

STOPPER, WINCH MOTOR

38625

BOLT, STUD WINCH MOTOR

38626

BUSHING, STEPPED FEMALE WINCH MOTOR

38627

BUSHING, STEPPED MALE WINCH MOTOR

38629

WIRE, WINCH MOTOR

38639

WIRE (FOR WINCH MOTOR)

9009300811

Крепеж

9009300811

Крепеж

9009300811

Крепеж

9009400606

Крепеж

9009900222

Крепеж

9009904584

Крепеж

9321914008

Крепеж

9331116014

Крепеж

9338516016

Крепеж

9338516016

Крепеж

9412040800

Крепеж

9412040800

Крепеж

9412040800

Крепеж

9451100400

Крепеж

9451100800

Крепеж

9451100800

Крепеж

9451100800

Крепеж

9461240601

Крепеж

Код

Описание

38101

CASE SUB-ASSY, WINCH GEAR

38103

DRUM SUB-ASSY, WINCH

38104

SHAFT, WINCH OUTPUT

38105

COVER SUB-ASSY, WINCH GEAR CASE

38106A

CASE, WINCH BRAKE

38107

GEAR SUB-ASSY, WINCH PLANETARY, NO.1

38108

GEAR SUB-ASSY, WINCH PLANETARY, NO.2

38109

GEAR SUB-ASSY, WINCH PLANETARY, NO.3

38119A

SHAFT, WINCH DRIVE

38121

GASKET, WINCH GEAR CASE COVER

38137

SHAFT, WINCH INPUT

38151

SPACER, WINCH DRUM, NO.1

38152

SPACER, WINCH DRUM, NO.2

38172

GEAR, WINCH RING

38177

BOLT, WINCH SET

38178A

BOLT, WINCH GEAR CASE COVER

38185A

RING, WINCH 1 WAY CLUTCH SNAP

38186

SEAL, GEAR CASE COVER OIL

38187A

RING, WINCH

38187A

RING, WINCH

38188A

RING, WINCH CLUTCH SHIFT HANDLE

38202A

CLUTCH SUB-ASSY, WINCH, OUTER

38203

DISC SUB-ASSY, WINCH CLUTCH, INNER

38203

DISC SUB-ASSY, WINCH CLUTCH, INNER

38203

DISC SUB-ASSY, WINCH CLUTCH, INNER

38203

DISC SUB-ASSY, WINCH CLUTCH, INNER

38203

DISC SUB-ASSY, WINCH CLUTCH, INNER

38204A

CLUTCH SUB-ASSY, WINCH INNER

38205A

CASE SUB-ASSY, WINCH CLUTCH, OUTER

38207A

LEVER SUB-ASSY, WINCH CLUTCH SHIFT

38211C

SLEEVE, WINCH CLUTCH

38213B

PLATE, WINCH CAUTION, NO.5

38216

CLUTCH, WINCH 1 WAY

38217

DISC, WINCH CLUTCH, OUTER

38217

DISC, WINCH CLUTCH, OUTER

38217

DISC, WINCH CLUTCH, OUTER

38217

DISC, WINCH CLUTCH, OUTER

38217

DISC, WINCH CLUTCH, OUTER

38222B

FORK, WINCH CLUTCH SHIFT

38223B

HANDLE, WINCH CLUTCH SHIFT

38224

BOLT, WINCH CLUTCH SHIFT HANDLE

38225

KNOB, WINCH CLUTCH LEVER

38228A

ADAPTER, WINCH CLUTCH SHIFT

38231

SHOE, BRAKE

38231

SHOE, BRAKE

38233B

WASHER, WINCH CLUTCH INPUT SHAFT THRUST

38236A

WASHER, WINCH CLUTCH THRUST, NO.1

38236B

WASHWE, WINCH CLUTCH THRUST

38237A

WASHER, WINCH CLUTCH THRUST, NO.2

38311

RING, WINCH OUTPUT SHAFT SNAP

38312

SPACER, WINCH OUTPUT SHAFT, NO.2

38313A

SPRING, WINCH CLUTCH SHIFT HANDLE

38315A

PLUG, WINCH FILLER

38317B

PIN, WINCH CLUTCH SHIFT HANDLE SPRING

38341

HOOK, WINCH WIRE

38342

PIN, WINCH WIRE HOOK

38343

WINCH WIRE

9411050800

Крепеж

9615001500

Крепеж
