Каталог

Ближний Восток

Модель

HILUX

VIN

Дата

1997/08

Двигатель

2,7 литра, CBR, DOHC

Класс

DELUX SPECIFICATION

Фрейм

RZN149

КПП

механика

Опции

левый руль DOOR CONTROL BATTERY STANDARD CARBURETOR SPECIFICATION GENERAL COUNTRIES COMPLETED VEHICLE

Карбюратор TOYOTA HILUX

Код

Описание

21015

HOUSING SUB-ASSY, COIL

21112

HORN, AIR

21192

BREAKER

21205

JET SUB-ASSY, SLOW

21209

FLOAT SUB-ASSY

21251

JET, 1ST MAIN

21253

JET, 2ND MAIN

21255

JET, POWER

21271

SCREW, IDLE ADJUSTING

21272A

SCREW, ADJUSTING

21273

SCREW, THROTTLE ADJUSTING

21301

VALVE SUB-ASSY, NEEDLE

21341

VALVE, POWER

21347

VALVE, SOLENOID

21347A

GASKET(FOR VALVE, SOLENOID)

21351

PISTON, POWER

21609

DIAPHRAGM SUB-ASSY

21611

GASKET, MAIN JET

21617

GASKET, MAIN PASSAGE PLUG

21618

GASKET, NEEDLE VALVE SEAT

21621

GASKET, UNION NIPPLE

21621

GASKET, UNION NIPPLE

21622

GASKET, AIR HORN

21623

GASKET, BODY FLANGE

21627

GASKET, COIL HOUSING

21655A

RING, O(FOR SLOW JET)

21667

DIAPHRAGM

21669

DIAPHRAGM

21698

DIAPHRAGM

21698

DIAPHRAGM

21699A

BOOT(FOR ACCELERATION PUMP)

21723

SPRING, IDLE ADJUSTING

21723C

SPRING, IDLE ADJUST

21724

SPRING, THROTTLE ADJUSTING

21734

SPRING, POWER PISTON

21751

UNION, NIPPLE

21763

PIN, FLOAT LEVER

21781

PLUG, MAIN PASSAGE(FOR CARBURETOR JET)

21791

RING, SNAP, NO.1(FOR CARBURETOR LINK)

21791

RING, SNAP, NO.1(FOR CARBURETOR LINK)

21791

RING, SNAP, NO.1(FOR CARBURETOR LINK)

21791A

RING, SNAP

21811

BOLT, UNION NIPPLE

21821

SCREW, 2ND THROTTLE VALVE SET

2182113310

Крепеж

2182124030

Крепеж

2182124030

Крепеж

2182125010

Крепеж

2182125010

Крепеж

2182131140

Крепеж

21833

SCREW, SET, NO.1(FOR CARBURETOR BODY SET)

21852

NUT, THROTTLE LEVER SET

21865

SPRING

21881

WASHER, LOCK(FOR THROTTLE SHAFT)

2188538310

Крепеж

21934

SOLENOID, THROTTLE VALVE

21934E

RING, O(FOR SOLENOID VALVE)

21934F

GASKET

9007970017

Крепеж

9033903002

Крепеж

9092504006

Крепеж

9099992002

Крепеж

9099992002

Крепеж

9311016035

Крепеж

9321915010

Крепеж

9328016014

Крепеж

9451200600

Крепеж

9461110400

Крепеж
