Каталог

Европа

Модель

DYNA

VIN

Дата

2019/11

Двигатель

4 литра, дизель

Фрейм

XZU720

КПП

механика МКПП, 5 скоростей

Опции

левый руль 7,5 тонн DOUBLE TIRE GENERAL COUNTRIES IV3 SCB 804W

Радиатор и шланги TOYOTA DYNA

Код

Описание

16361

FAN

16400

RADIATOR ASSY

16400A

COCK SUB-ASSY, RADIATOR DRAIN

16400B

PLUG, RADIATOR DRAIN COCK

16400F

PACKING(FOR RADIATOR DRAIN COCK)

16400R

BUSHING(FOR RADIATOR)

16400S

COLLAR(FOR RADIATOR)

16453

PLATE, RADIATOR SIDE

16454

PLATE, RADIATOR SIDE

16455

BOLT, RADIATOR SIDE SUPPORT PLATE

16455

BOLT, RADIATOR SIDE SUPPORT PLATE

16470

TANK ASSY, RADIATOR RESERVE

16470A

HOSE OR PIPE(FOR RADIATOR RESERVE TANK)

16470B

CLAMP OR CLIP(FOR RADIATOR RESERVE TANK HOSE)

16470B

CLAMP OR CLIP(FOR RADIATOR RESERVE TANK HOSE)

16471

CAP SUB-ASSY, RESERVE TANK

16533B

SUPPORT, RADIATOR, NO.1

16534

SUPPORT, RADIATOR, NO.2

16553C

CLAMP, HOSE

16561

SEAL, RADIATOR TO SUPPORT, NO.1

16565A

CLIP

16567

HOSE(FOR RADIATOR RESERVE TANK)

16567A

CLIP(FOR RADIATOR RESERVE TANK HOSE)

16567A

CLIP(FOR RADIATOR RESERVE TANK HOSE)

16568

PIPE, RADIATOR TO RESERVE TANK

16571C

HOSE, RADIATOR, NO.1

16571D

CLIP, RADIATOR HOSE, NO.1

16571D

CLIP, RADIATOR HOSE, NO.1

16572D

HOSE, RADIATOR, NO.2

16572E

CLIP, RADIATOR HOSE, NO.2

16572E

CLIP, RADIATOR HOSE, NO.2

16575

HOSE, RADIATOR, NO.5

16575A

CLIP, RADIATOR HOSE, NO.5

16575A

CLIP, RADIATOR HOSE, NO.5

16582

BRACKET, RADIATOR, NO.1

16583

BRACKET, RADIATOR, NO.2

16585

BRACKET, RADIATOR, NO.3

16586

BRACKET, RADIATOR, NO.4

16592

GUIDE, RADIATOR AIR, NO.3

16593

GUIDE, RADIATOR AIR, NO.1

16594

GUIDE, RADIATOR AIR, NO.2

16711

SHROUD, FAN

7728137400

Крепеж

9011906182

Крепеж

9011906960

Крепеж

9017906293

Крепеж

9046713020

Крепеж

9151160612

Крепеж

9151160612

Крепеж

9151160612

Крепеж

9151160612

Крепеж

9155180614

Крепеж

9155180614

Крепеж

9155180620

Крепеж

9155180814

Крепеж

9155180820

Крепеж

9155180820

Крепеж

9415180800

Крепеж

9415180800

Крепеж

SZ95031027

Крепеж

Код

Описание

16027

PIPE SUB-ASSY, TURBO WATER, NO.1

16027A

BOLT, UNION(FOR TURBO WATER PIPE)

16027B

GASKET(FOR TURBO WATER PIPE)

16027B

GASKET(FOR TURBO WATER PIPE)

16028

PIPE SUB-ASSY, TURBO WATER, NO.2

16028C

RING, O(FOR TURBO WATER PIPE)

16028D

BOLT, UNION, NO.1(FOR TURBO WATER PIPE)

16028D

BOLT, UNION, NO.1(FOR TURBO WATER PIPE)

16028E

GASKET, NO.1(FOR TURBO WATER PIPE)

16028E

GASKET, NO.1(FOR TURBO WATER PIPE)

16028E

GASKET, NO.1(FOR TURBO WATER PIPE)

16028E

GASKET, NO.1(FOR TURBO WATER PIPE)

16206

PIPE SUB-ASSY, WATER BY-PASS

16206A

PIPE SUB-ASSY, WATER BY-PASS, NO.2

16207

PIPE SUB-ASSY, WATER BY-PASS, NO.2

16258C

GASKET(FOR WATER BY-PASS PIPE)

16258C

GASKET(FOR WATER BY-PASS PIPE)

16261N

HOSE, WATER BY-PASS, NO.2

16268F

RING, O(FOR WATER BY-PASS PIPE)

16268F

RING, O(FOR WATER BY-PASS PIPE)

16268F

RING, O(FOR WATER BY-PASS PIPE)

16328

GASKET, WATER INLET PIPE

16331

OUTLET, WATER

16331A

THERMOSTAT

16331F

CAP SUB-ASSY(FOR WATER OUTLET)

16333

HOUSING, WATER OUTLET

16333B

RING, O(FOR WATER OUTLET HOUSING)

16341

GASKET, WATER OUTLET

16346

GASKET, THERMOSTAT

16507

PIPE SUB-ASSY, RADIATOR

16671

VALVE, WATER

1701

переход к группе запчастей

1701

переход к группе запчастей

8716

переход к группе запчастей

8716

переход к группе запчастей

8716

переход к группе запчастей

8716

переход к группе запчастей

9033916003

Крепеж

9033916003

Крепеж

9046626004

Крепеж

9046626004

Крепеж

9155180820

Крепеж

SH55210820

Крепеж

SH55210820

Крепеж

SH55210820

Крепеж

SH55210820

Крепеж

SH55210850

Крепеж

SH55210860

Крепеж

SH55211028

Крепеж

SH55211075

Крепеж

SZ10508055

Крепеж
