Карбюратор TOYOTA CORONA

21015

HOUSING SUB-ASSY, COIL

21112

HORN, AIR

21121

CASE, THERMOSTAT

21206

STRAINER SUB-ASSY

21209

FLOAT SUB-ASSY

21301

VALVE SUB-ASSY, NEEDLE

21334

VALVE, CHOKE

21352

PISTON, VACUUM

21371

CAM, 1ST IDLE

21372

FOLLOWER, 1ST IDLE CAM

21414

SHAFT, CHOKE

21452

LEVER, PUMP

21471

LINK, PUMP CONNECTING

21474

LINK, CONNECTING

21482

CONNECTOR, PISTON

21491

ROD, SLIDING

21531

RETAINER, COIL HOUSING

21536

PLATE, COIL HOUSING

2159834081

Крепеж

21618

GASKET, NEEDLE VALVE SEAT

21621

GASKET, UNION NIPPLE

21621

GASKET, UNION NIPPLE

21626

GASKET, CASE

21627

GASKET, COIL HOUSING

21697

BOOT(FOR SLIDING ROD)

21699

BOOT(FOR PUMP PLUNGER)

21735

SPRING, PUMP ARM

21736

SPRING, 1ST IDLE CAM

21751

UNION, NIPPLE

21763

PIN, FLOAT LEVER

21764

PIN, PISTON(FOR VACUUM PISTON)

21791

RING, SNAP, NO.1(FOR CARBURETOR LINK)

2182131140

Крепеж

21823

SCREW, CHOKE, VALVE SET

21824

SCREW, SET(FOR 1ST IDLE CAM FOLLOWER SET)

21826

SCREW, PUMP ARM SET

21827

SCREW, CONNECTOR SET

21836

SCREW, THERMOSTAT CASE SET

21837

SCREW, COIL HOUSING SET

21884

WASHER, THERMOSTAT CASE SET

21884

WASHER, THERMOSTAT CASE SET

9321915014

Крепеж

9451100300

Крепеж

9451100300

Крепеж

9451100500

Крепеж

9451100500

Крепеж

9461110400

Крепеж

9461110400

Крепеж

9538101610

Крепеж

21129

COVER(FOR THERMOSTATIC VALVE)

21205

JET SUB-ASSY, SLOW

21211

VENTURI, 1ST SMALL

21212

VENTURI, 2ND SMALL

21251

JET, 1ST MAIN

21253

JET, 2ND MAIN

21255

JET, POWER

21291

GLASS, LEVEL GAGE

21313

BALL, STEEL, NO.1(FOR DISCHARGE WEIGHT)

21314

BALL, STEEL, NO.2(FOR PUMP PLUNGER)

21335

VALVE, THERMOSTATIC

21341

VALVE, POWER

21351

PISTON, POWER

21353

PLUNGER, PUMP

21511

CLAMP, LEVEL GAGE

21538

RETAINER, BALL CHECK

21561

WEIGHT, PUMP DISCHARGE

21572

STOP, POWER PISTON

21575

STOPPER, B(FOR DISCHARGE WEIGHT)

21611

GASKET, MAIN JET

21611

GASKET, MAIN JET

21614

GASKET, VENTURI

21614

GASKET, VENTURI

21617

GASKET, MAIN PASSAGE PLUG

21617

GASKET, MAIN PASSAGE PLUG

21625

GASKET, LEVEL GAGE

21641

GASKET(FOR THERMOSTATIC VALVE COVER)

21649

GASKET(FOR PUMP DISCHARGE WEIGHT STOPPER)

21659

RING, O(FOR THERMOSTATIC VALVE)

21677

PLUG

21722

SPRING, PUMP DAMPING

21734

SPRING, POWER PISTON

21781

PLUG, MAIN PASSAGE(FOR CARBURETOR JET)

21781

PLUG, MAIN PASSAGE(FOR CARBURETOR JET)

2182125010

Крепеж

21831

SCREW, POWER PISTON STOP

21842

SCREW, SET(FOR CARBURETOR LEVEL GAGE CLAMP SET)

2451200600

Крепеж

9315016020

Крепеж

9321914018

Крепеж

9321914018

Крепеж

9451100400

Крепеж

9451100400

Крепеж

9451100400

Крепеж

21113

FLANGE, CARBURETOR

21123

HOUSING, DIAPHRAGM

21138

CAP, DIAPHRAGM

21271

SCREW, IDLE ADJUSTING

21272

SCREW, 1ST IDLE ADJUSTING

21273

SCREW, THROTTLE ADJUSTING

21331

VALVE, 1ST THROTTLE

21332

VALVE, 2ND THROTTLE

21412

SHAFT, 1ST THROTTLE

21413

SHAFT, 2ND THROTTLE

21431

ARM, 1ST THROTTLE SHAFT

21447

LEVER, DIAPHRAGM

21449

LEVER, 2ND KICK

21453

LEVER, 1ST THROTTLE

21456

LEVER, 1ST THROTTLE IDLE ADJUSTING, NO.1

21526

SUPPORT, BACK SPRING

21557

SPACER(FOR 1ST IDLE CAM)

21581

SHIM, 1ST THROTTLE SHAFT

21581

SHIM, 1ST THROTTLE SHAFT

21581

SHIM, 1ST THROTTLE SHAFT

21622

GASKET, AIR HORN

21623

GASKET, BODY FLANGE

21645

GASKET, DIAPHRAGM, CAP

21647

GASKET, DIAPHRAGM HOUSING CAP

21672

CAP

21698

DIAPHRAGM

21723

SPRING, IDLE ADJUSTING

21724

SPRING, THROTTLE ADJUSTING

21726

SPRING, 1ST IDLE ADJUSTING

21756

SPRING, BACK(FOR THROTTLE SHAFT)

21794

RING, RETAINER, NO.1(FOR THROTTLE SHAFT)

21794

RING, RETAINER, NO.1(FOR THROTTLE SHAFT)

2179440070

Крепеж

21821

SCREW, 2ND THROTTLE VALVE SET

21822

SCREW, 1ST THROTTLE VALVE SET

21834

SCREW, SET, NO.2(FOR CARBURETOR BODY SET)

21852

NUT, THROTTLE LEVER SET

21867

SPRING, DIAPHRAGM

21868

SPRING, DIAPHRAGM RELIEF

21881

WASHER, LOCK(FOR THROTTLE SHAFT)

2189734230

Крепеж

9321914014

Крепеж

9321914018

Крепеж

9321915018

Крепеж

9451100400

Крепеж

9451100400

Крепеж

9451100500

Крепеж

9451200600

Крепеж

9461110300

Крепеж

21015

HOUSING SUB-ASSY, COIL

21112

HORN, AIR

21121

CASE, THERMOSTAT

21129

COVER(FOR THERMOSTATIC VALVE)

21205

JET SUB-ASSY, SLOW

21206

STRAINER SUB-ASSY

21209

FLOAT SUB-ASSY

21211

VENTURI, 1ST SMALL

21212

VENTURI, 2ND SMALL

21251

JET, 1ST MAIN

21253

JET, 2ND MAIN

21255

JET, POWER

21291

GLASS, LEVEL GAGE

21301

VALVE SUB-ASSY, NEEDLE

21313

BALL, STEEL, NO.1(FOR DISCHARGE WEIGHT)

21314

BALL, STEEL, NO.2(FOR PUMP PLUNGER)

21335

VALVE, THERMOSTATIC

21341

VALVE, POWER

21351

PISTON, POWER

21352

PISTON, VACUUM

21353

PLUNGER, PUMP

2139934190

Крепеж

21482

CONNECTOR, PISTON

21511

CLAMP, LEVEL GAGE

21531

RETAINER, COIL HOUSING

21536

PLATE, COIL HOUSING

21538

RETAINER, BALL CHECK

21572

STOP, POWER PISTON

21575

STOPPER, B(FOR DISCHARGE WEIGHT)

21611

GASKET, MAIN JET

21611

GASKET, MAIN JET

21614

GASKET, VENTURI

21614

GASKET, VENTURI

21617

GASKET, MAIN PASSAGE PLUG

21617

GASKET, MAIN PASSAGE PLUG

21618

GASKET, NEEDLE VALVE SEAT

21621

GASKET, UNION NIPPLE

21621

GASKET, UNION NIPPLE

21622

GASKET, AIR HORN

21625

GASKET, LEVEL GAGE

21626

GASKET, CASE

21627

GASKET, COIL HOUSING

21641

GASKET(FOR THERMOSTATIC VALVE COVER)

21649

GASKET(FOR PUMP DISCHARGE WEIGHT STOPPER)

21659

RING, O(FOR THERMOSTATIC VALVE)

21699

BOOT(FOR PUMP PLUNGER)

21722

SPRING, PUMP DAMPING

21734

SPRING, POWER PISTON

21751

UNION, NIPPLE

21763

PIN, FLOAT LEVER

21764

PIN, PISTON(FOR VACUUM PISTON)

21781

PLUG, MAIN PASSAGE(FOR CARBURETOR JET)

21781

PLUG, MAIN PASSAGE(FOR CARBURETOR JET)

2182125010

Крепеж

2182131140

Крепеж

21827

SCREW, CONNECTOR SET

21831

SCREW, POWER PISTON STOP

21836

SCREW, THERMOSTAT CASE SET

21837

SCREW, COIL HOUSING SET

21842

SCREW, SET(FOR CARBURETOR LEVEL GAGE CLAMP SET)

21884

WASHER, THERMOSTAT CASE SET

21884

WASHER, THERMOSTAT CASE SET

9321016014

Крепеж

9321914018

Крепеж

9321914018

Крепеж

9321915014

Крепеж

9451100300

Крепеж

9451100400

Крепеж

9451100400

Крепеж

9451100400

Крепеж

9451100500

Крепеж

9451100500

Крепеж

21123

HOUSING, DIAPHRAGM

21138

CAP, DIAPHRAGM

21275

SCREW, ADJUSTING

21334

VALVE, CHOKE

21371

CAM, 1ST IDLE

21372

FOLLOWER, 1ST IDLE CAM

2139944100

Крепеж

21414

SHAFT, CHOKE

21474

LINK, CONNECTING

21483

CONNECTOR, NO.1

21491

ROD, SLIDING

2152424230

Крепеж

21526

SUPPORT, BACK SPRING

2159834081

Крепеж

21645

GASKET, DIAPHRAGM, CAP

21647

GASKET, DIAPHRAGM HOUSING CAP

21664

LEVER(FOR DASH POT OR POSITIONER)

21677

PLUG

21679

POSITIONER

21697

BOOT(FOR SLIDING ROD)

21698

DIAPHRAGM

21731

SPRING, DASH POT OR POSITIONER ADJUSTING

21736

SPRING, 1ST IDLE CAM

21791

RING, SNAP, NO.1(FOR CARBURETOR LINK)

21791

RING, SNAP, NO.1(FOR CARBURETOR LINK)

21791

RING, SNAP, NO.1(FOR CARBURETOR LINK)

2179440070

Крепеж

21823

SCREW, CHOKE, VALVE SET

21824

SCREW, SET(FOR 1ST IDLE CAM FOLLOWER SET)

21843

SCREW OR PIN (FOR DASH POT OR POSITIONER LEVER)

21867

SPRING, DIAPHRAGM

21887

WASHER(FOR CONNECTING LINK SETTING)

21934

SOLENOID, THROTTLE VALVE

9231914014

Крепеж

9315016020

Крепеж

9321914018

Крепеж

9321915018

Крепеж

9451100300

Крепеж

9451100400

Крепеж

9451100400

Крепеж

9451100500

Крепеж

9451200600

Крепеж

9461110300

Крепеж

9461110400

Крепеж

21113

FLANGE, CARBURETOR

21271

SCREW, IDLE ADJUSTING

21272

SCREW, 1ST IDLE ADJUSTING

21273

SCREW, THROTTLE ADJUSTING

21331

VALVE, 1ST THROTTLE

21332

VALVE, 2ND THROTTLE

21412

SHAFT, 1ST THROTTLE

21413

SHAFT, 2ND THROTTLE

21431

ARM, 1ST THROTTLE SHAFT

21447

LEVER, DIAPHRAGM

21449

LEVER, 2ND KICK

21452

LEVER, PUMP

21453

LEVER, 1ST THROTTLE

21456

LEVER, 1ST THROTTLE IDLE ADJUSTING, NO.1

21471

LINK, PUMP CONNECTING

21557

SPACER(FOR 1ST IDLE CAM)

21581

SHIM, 1ST THROTTLE SHAFT

21581

SHIM, 1ST THROTTLE SHAFT

21581

SHIM, 1ST THROTTLE SHAFT

21623

GASKET, BODY FLANGE

21672

CAP

21723

SPRING, IDLE ADJUSTING

21724

SPRING, THROTTLE ADJUSTING

21726

SPRING, 1ST IDLE ADJUSTING

21735

SPRING, PUMP ARM

21756

SPRING, BACK(FOR THROTTLE SHAFT)

21756

SPRING, BACK(FOR THROTTLE SHAFT)

21794

RING, RETAINER, NO.1(FOR THROTTLE SHAFT)

21794

RING, RETAINER, NO.1(FOR THROTTLE SHAFT)

21821

SCREW, 2ND THROTTLE VALVE SET

21822

SCREW, 1ST THROTTLE VALVE SET

21826

SCREW, PUMP ARM SET

21834

SCREW, SET, NO.2(FOR CARBURETOR BODY SET)

21852

NUT, THROTTLE LEVER SET

21868

SPRING, DIAPHRAGM RELIEF

21881

WASHER, LOCK(FOR THROTTLE SHAFT)

9056004343

Крепеж

9451200600

Крепеж

9461110400

Крепеж

9538101610

Крепеж

21015

HOUSING SUB-ASSY, COIL

21112

HORN, AIR

21192

BREAKER

21206

STRAINER SUB-ASSY

21209

FLOAT SUB-ASSY

21301

VALVE SUB-ASSY, NEEDLE

21452

LEVER, PUMP

21471

LINK, PUMP CONNECTING

2153136110

Крепеж

21551

HOLDER, BACK SPRING

21618

GASKET, NEEDLE VALVE SEAT

21621

GASKET, UNION NIPPLE

21621

GASKET, UNION NIPPLE

21627

GASKET, COIL HOUSING

21699

BOOT(FOR PUMP PLUNGER)

21735

SPRING, PUMP ARM

21751

UNION, NIPPLE

21763

PIN, FLOAT LEVER

2176536120

Крепеж

21791

RING, SNAP, NO.1(FOR CARBURETOR LINK)

21799

RING, E, TOP

2183244051

Крепеж

2183436120

Крепеж

2184136120

Крепеж

2187536120

Крепеж

2187540040

Крепеж

21077

COVER(FOR AUXILIARY ACCELERATION PUMP)

21129

COVER(FOR THERMOSTATIC VALVE)

21203

BLEEDER SUB-ASSY, 1ST MAIN AIR

21205

JET SUB-ASSY, SLOW

21211

VENTURI, 1ST SMALL

21212

VENTURI, 2ND SMALL

21249

JET, AIR BLEED, NO.2

21251

JET, 1ST MAIN

21253

JET, 2ND MAIN

21255

JET, POWER

21259

JET, AIR BLEED

21291

GLASS, LEVEL GAGE

21299

NET, PUMP FILTER

2130836110

Крепеж

21312

BALL, STEEL

21335

VALVE, THERMOSTATIC

21353

PLUNGER, PUMP

21449

LEVER, 2ND KICK

21456

LEVER, 1ST THROTTLE IDLE ADJUSTING, NO.1

21474

LINK, CONNECTING

21511

CLAMP, LEVEL GAGE

21561

WEIGHT, PUMP DISCHARGE

21576

CLIP, PUMP STRAINER

21611

GASKET, MAIN JET

21611

GASKET, MAIN JET

21612

GASKET, POWER VALVE

2161236110

Крепеж

21614

GASKET, VENTURI

21614

GASKET, VENTURI

21617

GASKET, MAIN PASSAGE PLUG

21617

GASKET, MAIN PASSAGE PLUG

21622

GASKET, AIR HORN

21625

GASKET, LEVEL GAGE

21631

GASKET, MAIN GUIDE

21641

GASKET(FOR THERMOSTATIC VALVE COVER)

21648

PACKING(FOR SLOW VALVE COVER)

21659

RING, O(FOR THERMOSTATIC VALVE)

21667

DIAPHRAGM

21722

SPRING, PUMP DAMPING

21736

SPRING, 1ST IDLE CAM

2176536120

Крепеж

2177636110

Крепеж

21781

PLUG, MAIN PASSAGE(FOR CARBURETOR JET)

21781

PLUG, MAIN PASSAGE(FOR CARBURETOR JET)

21786

PLUG, PUMP PASSAGE

21787

PLUG, PUMP JET

21797

RING, SNAP, NO.4(FOR CARBURETOR LINK)

21797

RING, SNAP, NO.4(FOR CARBURETOR LINK)

2179936120

Крепеж

2181636120

Крепеж

2181736120

Крепеж

2183236110

Крепеж

2183244120

Крепеж

2183436110

Крепеж

21842

SCREW, SET(FOR CARBURETOR LEVEL GAGE CLAMP SET)

2185236110

Крепеж

2187436120

Крепеж

2188136120

Крепеж

21934

SOLENOID, THROTTLE VALVE

21113

FLANGE, CARBURETOR

21165

INSULATOR

21171

CHAMBER, DIAPHRAGM

21271

SCREW, IDLE ADJUSTING

21272

SCREW, 1ST IDLE ADJUSTING

21273

SCREW, THROTTLE ADJUSTING

21281

NOZZLE, IDLE

2133236120

Крепеж

2133236120

Крепеж

21431

ARM, 1ST THROTTLE SHAFT

21453

LEVER, 1ST THROTTLE

21461

LEVER, 1ST IDLE

21463

LEVER, 2ND THROTTLE

21557

SPACER(FOR 1ST IDLE CAM)

21557

SPACER(FOR 1ST IDLE CAM)

21629

GASKET, IDLE NOZZLE

21634

GASKET, SLOW PASSAGE PLUG

21645

GASKET, DIAPHRAGM, CAP

21723

SPRING, IDLE ADJUSTING

21724

SPRING, THROTTLE ADJUSTING

21726

SPRING, 1ST IDLE ADJUSTING

21728

SPRING, THROTTLE VALVE RETURN

21756

SPRING, BACK(FOR THROTTLE SHAFT)

21784

PLUG, SLOW PASSAGE

21797

RING, SNAP, NO.4(FOR CARBURETOR LINK)

2182936120

Крепеж

2183244051

Крепеж

21833

SCREW, SET, NO.1(FOR CARBURETOR BODY SET)

2184536120

Крепеж

21852

NUT, THROTTLE LEVER SET

21852

NUT, THROTTLE LEVER SET

21867

SPRING, DIAPHRAGM

2187436120

Крепеж

2187436120

Крепеж

21881

WASHER, LOCK(FOR THROTTLE SHAFT)

21881

WASHER, LOCK(FOR THROTTLE SHAFT)
